Features

  • Smallest size and rugged design
  • Very high self-resonant frequency
  • Low Cmin values and low torque
  • High voltage relative to small size
  • Integrated flanges for easy installation
  • Antimagnetic lead screws for special applications

Applications

Technical Specifications

Capacitance Cmax range
30 - 125 pF
Upt range 5 - 20 kV

max. current IRMS at 13.56 MHz

13 - 36 ARMS
Inductance ≤ 8 nH
Diameter 35 mm
Height 105 - 127 mm
Cooling systemConvection
RoHS conformAvailable
